6. Commissioning, operation
Specifications
Description Ingress protection
Angular connector DIN 175301-803 A IP 65
Circular connector M12 x 1 (4-pin) IP 67
Circular connector M16 x 0.75 (5-pin) IP 67
Bayonet connector IP 67
CANopen M12 x 1 (5-pin) IP 67
USB IP 67
Cable outlet IP 67
The stated ingress protection (per IEC 60529) only applies when plugged in using
mating connectors that have the appropriate ingress protection.
6.3 Functional check
The output signal must be proportional to the prevailing pressure. If this is not the case, this may indicate
a damaged diaphragm. In this case, see chapter 8 "Faults".
6.4 Installation of the service interface
Only required for analogue instruments
Hardware requirement:
■ Spare USB port
■ USB adapter cable (order No.: 13193075 incl. software CD)
■ Suitable voltage supply for the pressure transmitter
System requirement:
■ 32-bit operating system Microsoft ® Windows ® 2000, XP, Vista or Windows ® 7
■ WIKA software EasyCom 2011 (CD containing software included with order No.: 13193075 or is
available for download at www.wika.com)
