KRAMER ELECTRONICS LTD.

1

1.

INTRODUCTION

Congratulations on the purchase of this Kramer Electronics device. Since 1981 Kramer is dedicated to the

development and manufacture of high quality video/audio equipment. Throughout this period the Kramer line

has become an integral part of many of the best production and presentation facilities around the world. In

recent years, Kramer has redesigned and upgraded most of its lines, rendering the products more efficient and

“user-friendly”. Kramer’s line of professional video/audio electronics is one of the most versatile and complete

available and is a true leader in terms of quality, workmanship, price/performance ratio and innovation. In

addition to the devices presented here, Kramer offers a vast range of high quality distribution amplifiers,

switchers, processors, interfaces, controllers and computer-related products.

2.

UNPACKING and CONTENTS

The items contained in the Kramer package are listed below. Please save the original box and packaging

materials for possible future transportation and shipment of the device.

A Kramer “twisted pair” receiver / transmitter

AC power cable (where applicable)

User Manual

Kramer concise product catalog

4 rubber feet

3.

GETTING STARTED

The fastest way to get started is to slow down and do everything right the first time. Taking 15 minutes to read

the manual may save a few hours later, and usually there is no need to read the whole manual. Since each

section opens with an overview of the section, users may determine its necessity for their particular needs.

3.1 Factors Affecting Quality of Results

There are many factors affecting the quality of results when signals are transmitted via coaxial cable from a

source to an acceptor:

Connection cables

- Low quality cables are susceptible to interference. They degrade signal quality due

to poor matching, and cause elevated noise levels. They should therefore be of the best quality.

Sockets and connectors of the sources and acceptors

- So often ignored, they should be of highest

quality since "Zero Ohm" connection resistance is the target. Sockets and connectors must also match the

required impedance (75ohm in video). Cheap, low quality connectors tend to rust, thus causing breaks in the

signal path.

Amplifying circuitry

- Must have quality performance when the desired end result is high linearity, low

distortion and low noise operation.

Distance between sources and acceptors

- Plays a major role in the final result. For long distances

(over 15 meters) between sources and acceptors, special measures should be taken in order to avoid cable

losses. These include using higher quality cables, adding line amplifiers, or using twisted pair or fiber optic

codecs.

Interference from neighboring electrical appliances

- These can have an adverse effect on signal

quality. Balanced audio lines are less prone to interference, but unbalanced audio should be installed far from

any main power cables, electric motors, transmitters, etc., even when the cables are shielded.

3.2 Optional Accessories

The following accessories, available from Kramer, can enhance implementation of other Kramer devices. For

information regarding cables and additional accessories, contact your Kramer dealer.

RK-50R/RK-80 Rack Mechanical Adapters

-

Used to adapt non-standard size machines to a

standard 1U rack. One or more machines may be installed on each adapter

.

BNC "Y" Connector

-

Used for looping purposes and splits the incoming signal to enable connection

of an additional machine.

Termination Plug

-

Used to terminate the line to 75ohm for proper matching

.
