SPECIFICATIONS (Continued)
FC-4042 FC-4043 FC-4044 FC-4208
Configuration Transcoder Transcoder Decoder Audio Transcoder
Inputs 1 component (Y, R-Y,
B-Y), 1V, 0.7V, 0.7 Vpp
/75
Ω,
1 RGBS 0.7Vpp / 75
Ω,
for 100% saturation on
BNCs
Decoder: 1 Composite video,
1Vpp/75
Ωs on a BNC,
1 s-Video: 1Vpp/75
Ω (Y),
0.3Vpp/75
Ω (C) on a 4P
connector
Encoder: 1 (Y, R-Y, B-Y) 1V,
0.7V, 0.7 Vpp /75
Ω on BNCs
1 Composite video,
1Vpp/75
Ωs on a BNC,
1 s-Video: 1Vpp/75
Ω (Y),
0.3Vpp/75
Ω (C) on a 4P
connector
4 balanced, +4dBm
/50k
Ω
on female XLRs
4 unbalanced, 1Vpp /
50k
Ω
on RCAs.
Outputs 1 RGB 0.7Vpp / 75
Ω,
Sync 2Vpp/75
Ωs, TTL
level unloaded, for
100% saturation on
BNCs, 1 component
(Y, R-Y, B-Y), 1V,
0.7V, 0.7 Vpp /75
Ω,
BNCs
Decoder: 1V, 0.7V, 0.7 Vpp
/75
Ω (Y, R-Y, B-Y), BNCs
Encoder: 1Vpp/75
Ω
(Composite, BNC)
Y/C: 1Vpp/75
Ω (Y),
0.3Vpp/75
Ω (C), 4P connector
Component: 1V, 0.7V,
0.7Vpp /75
Ω, BNCs
RGB: 0.7Vpp/75
Ω, for 100%
saturation, Composite sync:
2Vpp/75
Ω, BNCs
4 unbalanced, 1Vpp/50
Ω
,
RCAs
4 balanced, +4dBm/50
Ω
,
18Vpp max., male XLRs
Diff. Gain 0.21%
Diff. Phase 0.19Deg.
K-Factor 0.4% 1.2 %
Non Linearity Less than 0.2% Less than 0.2%
DC Clamp
Error ±20 mV ±20 mV
Residual SC Composite to Y=30 mV, Y/C
to Y = 15 mV Composite to Y=30mV
Y/C to Y = 15mV
Y S/N Ratio Better than 71dB
Audio
Bandwidth NA NA NA 20-30000Hz
Audio THD NA NA NA Less than 0.02%
Audio S/N
Ratio NA NA NA Better than 89dB
Dimensions
(W, D, H) 48 x 17.8 x 1U (cm) 19"
x 7" x 1U 48 x 17.8 x 1U (cm) 19" x 7"
x 1U 48 x 17.8 x 1U (cm) 19" x 7"
x 1U 48 x 17.8 x 1U (cm) 19" x
7" x 1U
Weight 2.6kg. (5.8lbs.) Approx. 2.6kg. (5.8lbs.) Approx. 2.6kg. (5.8lbs.) Approx. 2.4kg. (5.3lbs.) Approx.
Power Source 230VAC, 50/60Hz
(115VAC, U.S.A.)
7.6VA
230VAC, 50/60Hz,
(115VAC, U.S.A.) 19.5VA 230VAC, 50/60Hz,
(115VAC, U.S.A.) 6.9VA 230VAC, 50/60Hz
(115VAC, U.S.A.) 3.7VA
