KRAMER ELECTRONICS LTD.
PN: 2900-004001
Table of Contents
1 INTRODUCTION 1
1.1 A Word on Format Interfaces 1
1.2
Factors Affecting Quality of Results
2
2 SPECIFICATIONS 3
3 HOW DO I GET STARTED? 5
4 UNPACKING AND CONTENTS 5
4.1 Optional Accessories 5
5 FORMAT INTERFACES 6
5.1
Getting to Know Your FC-10
6
5.2 Getting to Know Your FC-19 7
5.3 Getting to Know Your FC-4041C 8
5.4
Getting to Know Your FC-4042
9
5.5
Getting to Know Your FC-4043
10
5.6 Getting to Know Your FC-4044 11
5.7 Getting to Know Your FC-4208 12
6 INSTALLATION 13
6.1
Rack Mounting
13
7
CONNECTING TO VIDEO DEVICES 13
8 CONNECTING TO AUDIO DEVICES (FC-4208 ONLY) 13
9 USING THE MACHINES 13
9.1 Powering on the Machine 13
9.2
Composite/YC Video Selection (FC-19, FC-4043, FC-4044 only)
13
9.3
Adjusting the HUE (FC-4043, FC-4044 only)
13
9.4 Looping (FC-4041C only) 13
9.5 Audio Level Control (FC-4208 only) 14
10 TYPICAL APPLICATIONS 14
10.1 Interfacing Between Two Video Formats 14
10.2 Using PC Graphics in YC Production 15
10.3 Typical Composite/YC to Component/RGB Conversion 15
10.4
Integrating a Composite/RGB source Into a Composite/YC Switcher
16
10.5
Audio Format Conversion
17
11 TAKING CARE OF YOUR MACHINE 18
12 TROUBLESHOOTING 19
12.1 Power and Indicators 19
12.2 Video Signal 20
Video Signal (continued) 21
12.3
Audio Signal (FC-4208 only)
21
