38 Kramer Protocol 3000
11 Kramer Protocol 3000
The FC-21ETH can be operated using serial commands from a PC, remote
controller or touch screen using the Kramer Protocol 3000.
This section describes:

Kramer Protocol 3000 syntax (see Section 11.1 )

Kramer Protocol 3000 commands (see Section 11.2 )
11.1 Kramer Protocol 3000 Syntax
11.1.1 Host Message Format
Start Address
(optional) Body Delimiter
# Destination_id@ Message CR
11.1.1.1 Simple Command
Command string with only one command without addressing:
Start Body Delimiter
# Command SP Parameter_1,Parameter_2,… CR
11.1.1.2 Command String
Formal syntax with commands concatenation and addressing:
Start Address Body Delimiter
# Destination_id@ Command_1
Parameter1_1,Parameter1_2,…|
Command_2
Parameter2_1,Parameter2_2,…|
Command_3
Parameter3_1,Parameter3_2,…|… CR
11.1.2 Device Message Format
Start Address
(optional) Body delimiter
~ Sender_id@ Message CR LF
11.1.2.1 Device Long Response
Echoing command:
Start Address
(optional) Body Delimiter
~ Sender_id@ Command SP [ Param1 ,Param2 …] result CR LF
