Kramer Electronics FC-24ETH - Manual (Page 17)

Initial Configuration and Use Overview 13
2. Using a Web browser, (see Section 6.1 and Section 7 ) browse to the
General Info home page (see Figure 14 ).
3. Click on Device Settings to browse to the Device Settings page, (see
Figure 16 ).
4. Enter the time and date manually, or enter the Time server address for
automatic time and date synchronization.
5. Click Save Changes.
6. Click on Communication to browse to the Communication page, (see
Figure 17 ).
7. Enter the IP address, mask and gateway for static IP addressing and Click
Set.
—Or—
Click DHCP On for dynamic IP addressing.
Note: If you have changed the IP from the default setting, you must reload
the General Info home page again using the new IP address.
8. Click on Serial Ports Settings to browse to the Serial Port Settings page,
(see Figure 18 ).
9. Associate the required serial ports with their corresponding TCP/UDP
settings.
10. For each associated serial port, enter the serial port configuration
parameters using the drop-down lists under Serial Configuration.
11. Click Save Changes.
12. If required, click on Security to browse to the Security page.
13. Click ON to activate security.
The user name and password credentials popup appears.
14. Enter the required user name and password.
