Technical Specifications
35
9
Technical Specifications
FC-21ETH
FC-22ETH
FC-24ETH
PORTS:
1 Ethernet on an RJ-45 connector
1 USB on a mini USB connector for programming
1 RS-232/RS-485
serial port on a 3-pin
terminal block
1 RS-232/RS-485
serial port on a 3-pin
terminal block
1 RS-232 serial port
on 3-pin terminal
blocks
1 RS-232/RS-485
serial port on a 3-pin
terminal block
3 RS-232 serial ports
on 3-pin terminal
blocks
MAXIMUM SERIAL
PORT BAUD
RATE:
115200bps
RS-232
COMMUNICATION:
Transparent up to 115200bps
OVERALL DEVICE
BAUDRATE
SUPPORT:
150kbps
140kbps
180kbps
SUPPORTED WEB
BROWSERS:
Microsoft IE V9.0 and higher
Google Chrome
Firefox V3.0 and higher
POWER
CONSUMPTION:
200mA
OPERATING
TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE
TEMPERATURE:
–40° to +70°C (–40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS:
12.1cm x 6.97cm x 2.48cm
(4.76” x 2.74” x 0.98”) W, D, H
18.8cm x 11.3cm x
2.5cm
(7.4” x 4.5” x 1”) W,
D, H
WEIGHT:
0.48kg (1.1lbs) approx.
0.72kg (1.59lbs)
approx.
ACCESSORIES:
Power adapter
OPTIONS:
19“ Rack adapter RK-3T
19“ Rack adapter
RK-T2B
Specifications are subject to change without noti
9.1
Data Handling Performance
The FC-21ETH, FC-22ETH and FC-24ETH are designed to support mainly AV-
relevant RS-232 communication.
These devices have overall data bandwidth limits which should be high enough in
most AV installations to support the required communication bandwidth.
