Your VS-81HDxl 8x1 HD/SD-SDI Switcher
4
To achieve the best performance:
• Connect only good quality connection cables, thus avoiding interference,
deterioration in signal quality due to poor matching, and elevated noise
levels (often associated with low quality cables)
• Avoid interference from neighboring electrical appliances that may
adversely influence signal quality and position your Kramer VS-81HDxl
away from moisture, excessive sunlight and dust
4 Your VS-81HDxl 8x1 HD/SD-SDI Switcher
Figure 1 and Table 1 define the VS-81HDxl 8x1 HD/SD-SDI Switcher.
