Technical Specifications

8 Technical Specifications

Table 3

includes the technical specifications:

Table 3: Technical Specifications

INPUTS:

of the VS-81HDxl 8x1 HD/SD-SDI Switcher

8 SDI SMPTE-259M, 292M, 344M, 424M serial video, 75 ohms on BNC

connectors

1 GENLOCK 75

Ω / Hi-Z on looping BNC connectors, bi-level, Tri-level inputs

OUTPUTS:

2 identical equalized and reclocked SMPTE-259M, 292M, 344M, 424M

outputs 75 ohms on BNC connectors
1 GENLOCK 75

Ω / Hi-Z on looping BNC connectors, bi-level, Tri-level inputs

MAX. OUTPUT LEVEL:

800mVpp /75 ohms

JITTER:

Better than 0.2UI

DATA RATE:

Up to 2.97Gbps

CONTROLS:

Front-panel, RS-232; RS-485, ETHERNET, infrared remote, contact closure,

and panel lock

POWER SOURCE:

Universal, 100-240V AC, 50/60Hz 22VA

DIMENSIONS:

19 inch (W), 7 inch (D), 1U (H) rack mountable

WEIGHT:

1.5kg (3.3lbs) approx.

ACCESSORIES:

Power cord, Null-modem adapter

OPTIONS:

External remote IR receiver cable

1 Specifications are subject to change without notice

2 P/N: C-A35M/IRR-50
