VS-66HN - Default Communication Parameters 21
8 Default Communication Parameters
RS-232
Protocol 2000 (Default) Protocol 3000
Baud Rate 9600 Baud Rate 9600
Data Bits 8 Data Bits 8
Stop Bits 1 Stop Bits 1
Parity None Parity None
Command Format HEX Command Format ASCII
Example (Output
1 to Input 1) 0x01, 0x81, 0x81, 0x81 Example (Output 1 to
Input 1) #VID1>1
Switching Protocol
P2000 –> P3000 P3000 –> P2000
Command 0x38, 0x80, 0x83, 0x81 Command #P2000
Front Panel Press and hold Output 1 and
Output 3 simultaneously Front Panel Press and hold Output 1
and Output 2 simultaneously
Ethernet
IP Address 192.168.1.39 TCP Port 5000 or 10001 or 50000
Subnet Mask 255.255.255.0 UDP Port 50000
