VS-66HN - Connecting the VS-66HN 6x6 HDMI Matrix Switcher 9
5 Connecting the VS-66HN 6x6 HDMI Matrix
Switcher
Always switch off the power to each device before connecting it to your
VS-66HN. After connecting your VS-66HN, connect its power and then
switch on the power to each device.
To connect the VS-66HN 6x6 HDMI Matrix Switcher as illustrated in the
example in Figure 3 :
1. Connect up to six HDMI sources (for example, DVD players) to the IN HDMI
connectors.
You do not have to connect all the sources.
2. Connect the six OUT HDMI connectors to up to six HDMI acceptors (for
example, LCD displays with built-in speakers).
You do not have to connect all the outputs.
3. If required, connect a PC/controller to the RS-232 port (see Section
6.6
)
and/or the Ethernet port (see Section 6.7 ).
4. Connect the device to the mains electricity (not shown in Figure 3 ).
5. If necessary, acquire the EDID (see Section
6.2
)
i
