16 VS-44FO - Connecting the VS-44FO
Note: When turning the machine ON, the last stored setup is shown in the
7-segment display.
5.5 Connecting the Ethernet Port
You can connect the VS-44FO over the Ethernet in the following ways:

For direct connection to the PC, use a crossover cable (see Section 5.5.1 )

For connection using a network hub or network router, use a straight-through
cable (see Section 5.5.2 )
5.5.1 Connecting the Ethernet Port Directly to a PC (Crossover
Cable)
You can connect the Ethernet port of the VS-44FO to the Ethernet port on your PC,
via a crossover cable with RJ-45 connectors.
This type of connection is recommended for identifying the VS-44FO
with the factory configured default IP address.
After connecting the Ethernet port, configure your PC as follows:
1. Right-click the My Network Places icon on your desktop.
2. Select Properties.
3. Right-click Local Area Connection Properties.
4. Select Properties.
The Local Area Connection Properties window appears.
5. Select the Internet Protocol (TCP/IP) and click the Properties Button (see
Figure 6 ).
