MATRIX ROUTING SWITCHER
1 bal/unbal 1 G4 G3 G2 G1 G0
Where bal=0 and unbal=1
the reply to the HEX code
19h 82h 80h 81h
would be (for a maximum VCA)
55h 82h 9Fh 81h
NOTE 7 – This code is reserved for internal use.
NOTE 8 - The serial number is replied as BCD code, with Most Significant Byte in the input byte and
Less Significant Byte in the output byte.
NOTE 9 – When OFF LINE mode, sending a switch instruction will store the data in the volatile matrix
memory, without effective switch. Switch will be done when ON LINE instruction.
When ON LINE mode, sending a switch instruction will execute normal switch.
NOTE 10 – POWER ON RESET. The output register has a value under the binar form :
1 0 POR1 POR0 P3 P2 P1 P0
P3…P0 : vca slope from 0 to 9 seconds
POR1 = 0 :
POR0 = 0 : vca max when power on.
POR0 = 1 : vca min when power on.
POR1 = 1 : recall vca when power on.
NOTE 11 – REFRESH the ON SCEEN DISPLAY. The GMOSD card will be restarted to be refreshed.

