4

VM-24H - Overview

3

Overview

The

VM−24H is a distribution amplifier for HDMI signals. The unit reclocks and

equalizes one of two selectable input signals and distributes it to four identical

outputs.

The VM-24H features:

A maximum data rate of 6.75Gbps ( 2.25Gbps per graphic channel)

HDMI

support for Deep Color, x.v.Color™, Lip Sync, CEC

3D pass-through

I-

EDIDPro™ Kramer Intelligent EDID Processing™, an intelligent EDID

handling and processing algorithm that ensures Plug and Play operation for

HDMI systems

The ability to acquire the EDID from one output, from several connected

outputs (auto-mix) or acquire the default EDID for fast and efficient

connection of the unit

Housing in a 19" 1U rack mountable enclosure

Power feeding from a 100-240V AC universal switching power supply

Control the VM-24H via:

The front panel buttons

The infrared remote control transmitter

The infrared remote extension cable transmitter, see

Section

‎3.2

RS-232 serial commands transmitted by a touch screen system, PC, or other

serial controller

3.1

Defining the VM-24H 2 Input 1:4 HDMI Distributor

This section defines the VM-24H.
