VM-24H - Connecting the VM-24H 9
5 Connecting the VM-24H
Always switch off the power to each device before connecting it to your
VM-24H. After connecting your VM-24H, connect its power and then
switch on the power to each device.
To connect the VM-24H, as illustrated in the example in Figure 3 , do the following:
1. Connect the two HDMI sources, for example, a DVD player and a set top box,
to the INPUT 1 and INPUT 2 connectors, respectively.
2. Connect the HDMI OUTPUT connectors to up to 4 HDMI acceptors, using
Kramer HDMI copper cables. In this example, connect the:

OUTPUT 1 connector to acceptor 1 (for example, a plasma display)

OUTPUT 2 connector to acceptor 2 (for example, an LCD TV)

OUTPUT 3 connector to acceptor 3 (for example, an LCD TV)
 OUTPUT 4 connector to acceptor 4 (for example, a plasma display)
Up to four outputs can be connected. Not all outputs need to be connected.
3. If required, connect a PC and/or controller to the RS-232 port (see
Section
‎6.1
).
4. Connect the power cord to the mains electricity (not shown in Figure 3 ).
5. If required, acquire the EDID (see Section ‎6.3 ).
