4 VM-114H2C - Overview
3 Overview
The VM-114H2C 2 Input 1:4 HDMI DA/2x CAT5 Outputs is a switcher/distribution
amplifier for HDMI and TP (twisted pair) signals. It reclocks and equalizes one of
two selectable input signals and distributes it to two HDMI and two TP outputs.
In particular, the VM-114H2C features:

A maximum data rate of 4.95Gbps (1.65Gbps per graphic channel),
6.75Gbps (2.25Gbps per graphic channel) maximum when using HDMI only

Non-volatile memory that reads and stores the default EDID or the EDID
block from one or a mix of the output display devices, so it can then provide
the EDID information to the source even if the display device is not
connected

I- EDIDPro™ Kramer Intelligent EDID Processing™, an intelligent EDID
handling & processing algorithm that ensures Plug and Play operation for
HDMI systems

HDMI support for
3D, Deep Color, x.v.Color™ and 7.1 uncompressed audio
channels (Dolby TrueHD, DTS-HD)

HDCP compliance

LEDs indicating the selected input and active output

IR remote control support and has a remote IR 3.5mm mini jack

12V DC power

Housing in a Kramer desktop enclosure
The VM-114H2C supports a range of:

Up to 90m (295ft) at 1080i, or up to 30m (98ft) at 1080p on shielded
BC-DGKat524 cable

Up to 90m (295ft) at 1080i, or up to 70m (230ft) at 1080p on shielded
BC-DGKat623 cable

Up to 100m (330ft) at 1080i or up to 90m (295ft) at 1080p on shielded
BC-DGKat7a23 cable
