10

VM-114H2C - Operating the VM-114H2C

5.2

Disabling/Enabling Deep Color Support

You can disable EDID deep color support to prevent signal deterioration when

using long twisted pair cables on INPUT 2.

To disable deep color and acquire EDID:

1. Disconnect the power.

2. Connect the output or outputs from which you want to acquire the EDID.

3. Connect the power while pressing the EDID READ button.

4. Perform steps 3 and 4 in

Section

‎5.1

.

To enable deep color and acquire EDID:

1. Disconnect the power.

2. Connect the output or outputs from which you want to acquire the EDID.

3. Connect the power while pressing the EDID SELECT button.

4. Perform steps 3 and 4 in

Section

‎5.1

.

5.3

RS-232 and IR Control and Pass-Through

The VM-114H2C can be controlled via RS-232 and infrared. Depending on how

the RS-232 and IR connections are configured, the device either responds to

control signals or transparently passes them through to another receiver or

transmitter. Three examples in

Sections

‎5.3.3

,

‎5.3.4

and

‎5.3.5

of various

configurations illustrate this functionality.
