© MuxLab Inc. VGA 1x4 Distribution Hub Installation Guide
Page 12
4.
Troubleshooting
The following table describes some of the problem symptoms, the
probable causes and possible solutions. If the information below
does not solve the problem, the technical support contact
information can be found at the end of this section.
Picture Power LED Probable Cause Possible Solution
No Image OFF No power Check power
connections
No Image ON Wiring Check continuity
Check correct wiring
Smearing ON Exceed cable length Reduce cable length
Adjust contrast and
brightness
Ghosting ON Impedance mismatch Check cabling
Try different VGA card
or display
Wrong colors ON Swapped pairs Check wiring
Loss of detail ON Exceed cable length Reduce cable length
Adjust contrast and
brightness
Image shakes ON Too much gain Adjust Gain and
Equalization on Active
VGA Balun Receiver.
