3.
Installation Procedure
3.1. Pre-Installation Checklist
The LongReach II Active CCTV Receiver Balun
(500124) is used to provide extended distance via a
copper twisted pair. Before installing the product, please
verify the following checklist to ensure that installation
takes place smoothly.
1. The 500124 is always connected to the receiver side
of a CCTV installation. For example, it is connected
directly to the video input ports of the CCTV DVR,
IP encoder or matrix switcher at the central
monitoring location.
2. The 500124 is used in conjunction with MuxLab’s
passive CCTV baluns (i.e.: 500009, 500022,
500024/29). The passive CCTV Balun is connected
at the CCTV source, which is usually the CCTV
camera.
3. For best image quality and operator safety, the DVR
should be properly grounded. If this is not possible,
then the 500124 should be properly grounded. Please
ensure that there is a building ground available.
Note: If more than one 500124 is connected to the
same DVR, only one balun needs to be properly
grounded.
