-Dimensions:
-Weight:
-Power Input:
-
88.0 x 482.0 x 205.5 (HxWxD) mm
Net 4.5kg Shipping 5.5kg
Net 9.9lb Shipping 12.1lb
20VAC
30VA max
Program Sources:
-Sum Input:
-Frequency Response:
-THD:
-Noise:
Unbalanced (RCA)
Sensitivity: 150mV (-14dBu)
Balanced (XLR)
Input Impedance: 1k3ohm
Sensitivity: 1mV (-57dBu)
Min Trim: -46dB
Input Sensitivity: 160mV (-13.5dBu)
Threshold: -46dBu (at output, ind of input)
15Hz - 17kHz
0.005%
Page Mic: -84dB
Other Inputs: -89dB
All measurements are reference to 1.5V (+6dBu)
(trim max)
(0dB/-3dB)
-Output:
Input Impedance:100kohm
1.5Vrms 600ohm
Max: 9Vrms
12 .SPECIFICATIONS
