Australian Monitor Essentials Microphone User Manual
Specifications
SPECIFICATIONS:
Type
Dynamic Microphone
Polar Pattern
Cardioid
Frequency Response
50Hz – 16kHz
Sensitivity:
-39dBV/Pa (11mV/Pa)
Max SPL:
132dB
Dynamic Range:
106dB
Phantom Power Requirement:
9-52VDC
Current Draw:
3mA
Output Configuration:
Transformerless
Output Impedance:
200 Ohms
Output Connector:
Gold plated 3 pin XLR male connector
Dimensions:
20mm x 620mm
Weight:
160g
