Chapter 4. Operation
61202066L1-1B T1 ESF CSU Rackmount User Manual 37
Tests
The T
EST
menus are used to initiate different types of tests and to view
test results. The T
EST
menu can be accessed by selecting T
ESTS
on the
main menu. The T
EST
menus are shown in Figure 4-5 through Figure 4-8.
They are followed by a discussion of each test item.
Figure 4-5. Display of Terminal Test Menu
Figure 4-6. Display of Terminal Test Results
T1 ESF CSU TEST OPTIONS
LOCAL TESTS REMOTE TESTS
1 RUN SELF-TEST 3 REMOTE LBS-NO LOOPBACK
2 LOCAL LBS-NO LOOPBACK 4 TEST PATTERN=NO PATTERN
CSU TEST RESULTS
CODE VIOLATION = 0
1 EXIT TEST
2 CLEAR VIOLATIONS
