AT-29xxSX Series Gigabit Ethernet Adapters Installation Guide
19
LEDs
All adapter models have two LEDs: LINK and ACT. The LINK LED
indicates an active link and the ACT (Activity) LED indicates data transfer
status. After the driver is loaded and the cables are connected properly.
The LINK LED is lit and the ACT LED is on if data traffic is present. See
Table 1.
Table 1. Fiber Optic Port LED Status
LED
State
Description
LINK
On
Valid fiber link.
Off
No fiber link.
ACT
Blinking
Data traffic is present
between the card and the
switch.
Off
Data traffic is not present.
