American Power Conversion RT XLI/XLICH User Manual
Page 22
18
Smart-UPS RT 15000/20000 VA 230 Vac Stack/Rack-Mount 6U User Manual
Menu Tree
The menu tree provides an overview of the top level menu screens.
Navigating sub menu screens
Use the UP/DOWN arrow keys to scroll through the list of functions and commands on a sub menu screen.
A after the last entry on a sub menu, indicates a continuation of the function/command list.
Use the UP/DOWN arrow keys to view the remaining entries in the list.
Use the ENTER key to select a command and move to sub menus associated with that function/command.
Overview Status
Screen
Chrg 000%
Load 000%
000Vin 000Vout 0Hz
1:1Runtime:00hr0m
Control
Status
Setup
Batteries
Logging
Display
Diags
Help
Main Menu
Screen
Control
Status
Setup
Batteries
Logging
Display
Help
Diags
