General Specifications (continued):
ProductionVIEW HD-SDI MV
Part Numbers:
999-5655-000 (NTSC)
999-5655-001 (PAL)
Compatible Cameras:
Vaddio, Panasonic, Sony & Canon (See Manual for Specific Models)
Video Formats Supported:
NTSC and PAL
Video Switcher:
6 x 2 (or Two 6 x 1)
Video Transitions:
Cross Fade, 9 Wipe options and Straight Cuts, Fade to Black
Video Inputs:
Five (5 -BNC)
One (1-DVI-I)
Preview or Multiviewer Output:
One (1-BNC) Preview or Multiviewer: HD-SDI or SD-SDI
Same resolution on the BNC and both HDMI Preview Outputs (see
Pg. 27)
Two (2-HDMI) Preview or Multiviewer Output:
HD-SDI or SD-SDI
Same resolution on the BNC and both HDMI Preview Outputs (see
Pg. 27)
Program Output:
One (1-BNC) Program Output:
HD-SDI or SD-SDI
Same resolution on both Program Outputs (see Pg. 27)
One (1-HDMI) Program Output:
HD-SDI or SD-SDI
Same resolution on both Program Outputs (see Pg. 27)
Camera Control Ports:
Six (6) RS-232 on RJ-45F
Control Interface:
One (1) RS-232 on DB-9
LCD Display:
8-line backlit LCD display
Power Requirements:
PowerRite 18 VDC, 2.78 Amp
Trigger Inputs (Inputs 1 & 2):
Cameras 1 & 2 have 6 presets each or Camera 1 can have 12
Tally Output:
Tally outputs for each of the six inputs
Weight:
9.5 lbs. (4.32kg) – approximate weight
Dimensions (H x W x D):
4” (10.16cm) x 16” (40.64cm) x 10” (25.4cm)
Supplied Cable: (PN443-5643-003)
One (1) HDMI to DVI-D Adapter Cable 10ft. (3m):
