ProductionVIEW HD-SDI MV
ProductionVIEW HD-SDI MV Manual - Document Number 342-0318 Rev. B
Page 20 of 36
ProductionVIEW HD-SDI MV Menu Structure
The ProductionVIEW HD-SDI MV has an 8-line LCD that displays the system menus. The menus are traversed with the
up/down arrows, select and cancel buttons. The menu structure is as follows:
1
st
Screen
ProductionVIEW HD-SDI MV
V01.00.XX
(software
version)
Main
Menu
Rescan Cameras
Rescan
Video
Video
Output
Menu
DVI
Input
Mode
SD
Video
Format
Default
Camera
Default
Preset
Default
Idle
Return
Pan
Dir
Menu
Tilt
Dir
Menu
Zoom
Dir
Menu
Preset
Pan
Speed
Preset
Tilt
Speed
Preset
Zoom
Speed
Triggers/Tally
Select
Follow
Prv
Canon
Shot
Time
Canon ND Filter
Canon Shutter Speed
Multiviewer
Cam
Search
Menu
CCU
Mode
Menu
System Menu
Rescan Cameras
>Select (Note: Rescans all RS-232 ports for camera inputs)
>Start
Rescan Video
>Select (Note: Resets all inputs, outputs and video processor)
>Start
Video Output Menu
>Select
>Video Output Menu
>Program
Output
HD 1080p/59.94Hz
HD
1080p/50Hz
HD
1080i/59.94Hz
HD
1080i/50Hz
HD
720p/59.94Hz
HD
720p/50Hz
SD 480i/29.97Hz
SD 576i/25Hz
HD 1080p/60Hz
HD
1080p/30Hz
HD
1080p/25Hz
HD 720p/30Hz
HD 720p/25Hz
>Preview Output
Note: The two-HDMI Outputs will always have identical outputs and cannot
be individually programmed.
HD
1080i/59.94Hz
HD
1080i/50Hz
HD
720p/59.94Hz
HD
720p/50
Hz
SD
480i
/29.97Hz
SD 576i/25 Hz
MV 1080p/59.94Hz
*
MV
1080p/50Hz
*
MV
1080i/
59.94Hz
MV
1080i/50Hz
HD 1080p/60Hz
HD
1080p/30
Hz
HD
1080p/25
Hz
HD
720p/30
Hz
HD
720p/25
Hz
HD
1080p/59.94
Hz
HD 1080p/50 Hz
Menu Section
*
MV
NOTE:
MV settings for the multiviewer bypass the video
processing engine. For best results, use the MV
1080p/59.94/50Hz for the multiviewer output for
fully adaptive deinterlacing, adaptive 3D noise
reduction, mosquito noise reduction, block
artifact reduction, adaptive detail enhancement
featuring sharpness and texture enhancement
with overshoot control, and adaptive contrast
enhancement.
