AutoTrak 2.0 Camera Tracking System
AutoTrak 2.0 Camera Tracking System - Document Number 342-0382 Rev. E Page 15 of 52
Basic System Configuration 2:
AutoTrak 2.0 999-7260-000 HD-18 IR Reference Camera and HD-20 Tracking Camera Kit with Quick Connect DVI/HDMI
Interface (North America Only)
Power to Camera
Differential HSDS Video from Camera
CVBS
BNC to RCA
Cat-5e
Power to
EZ
Port
Power to
Camera
CVBS
from
Camera
RS-232
Cat-5e
Std Quick-Connect
Box 998-1105-001
CVBS in
Video 2
Keyboard & Mouse
RGBHV Monitor
(Not Included)
Instructor’s Confidence
Monitor
(Not Included)
Simulated Video Feed
Quick-Connect DVI/HDMI - SR
Interface 998-1105-018
AutoTrak 2.0 IR Lanyard,
attached cable, Rechargeable
Belt Pack and 1-inch RP-SMA
Cat-5e
Cat-5e
HD-18
IR Reference
Camera with
Adapters and
Filters
Composite Video
feed to AutoTrak
2.0
HD-20
Tracking Camera
AutoTrak
2.0
HD-18-
HD-20
Mount
HD Video Monitors (Not Included)
Simulated Video Feeds
Note: Belt Pack is capable of
Transmitting Wireless Mic Audio at 2.4
GHz to Optional EasyTalk AutoTrak
2.0 Wireless Audio Interface
Cat-5e
Cat-5e Cable to EZ Power Video Port
AutoTrak 2.0 Quick-Connect
Box 998-1105-020
Sound System
(Not Included)
Balanced Line Level (on XLR +4dBu) or
Unbalanced Line Level (on RCA -10dBV)
RGBHV
Cat-5e
Cat-5e
4” RP-SMA
Antenna
YPbPr
DVI-D or
HDMI with
adapter
HDMI Video
T C60 Codec
(Not Included)
AutoTrak 2.0 CPU
Port 2 Port 1
Serial to Cat-5e
Control Adapters
Use Adapter P/N:
998-1001-232 on
these Ports
Optional Wireless Audio
EasyTalk AutoTrak 2.0 Wireless Audio Interface
Receiving Audio from Wireless Belt Pack at 2.4 GHz
24 VDC
PWR
Supply
24 VDC
PWR
Supply
