15
6. Specifications
Input Power 115 Volt/ 60Hz, 115 Volt/ 50Hz, 220 Volt/ 60 Hz, or 220 Volt/
50Hz
Stroke Length Control 0 – 100% control range
Resolution – 0.0625% increments
Stroke Adjustment response Approximately 1% per second
Analog Input
Operating Range 0 to 25.5mA (4-20 mA factory default)
Input Impedance 160 ohms
Minimum Span 2.0 mA
Isolation 500V from all other inputs, outputs and ground, optically
isolated
Conditioning 8 second running average.
Split Ranging and Reverse Acting accessible via calibration.
Analog Output
Operating Range 0 to 25.5mA (4-20 mA factory default)
Maximum Load 700 ohms
Minimum Span 2.0 mA
Conditioning None. Output represents current stroke position.
Split Ranging and Reverse Acting accessible via calibration.
Isolation 500V from all other inputs, outputs and ground, optically
isolated.
Status Input
Motor On/Off Optically isolated dry contact input. Open contact indicates
motor is off. Controller will then suspend all stroke control
action. Motor starter should provide a contact for connection
here.
Environmental
Rated Ambient Temperature -20
C to 40C (-4F to 104F)
Storage Ambient Temperature -25
C to 60C (-13F to 140F)
Enclosure NEMA7, IP66, NEMA4X
Approvals UL/ULC - NEMA 7
UL 1203: Class I, Division I, Groups C & D Hazardous
Locations
Cenelec–IP66
Cenelec – XP, Class I, Zone I, Group IIB, (EEx d IIb T6)
(DEMKO)
CE – LVD, EMC
