Napoleon Fireplaces Corner Model – WMFE1 - Manual (Page 2)

W415-0958 / C / 03.01.12
2
NOTE: Changes, other than editorial, are denoted by a vertical line in the margin.
TABLE OF CONTENTS
1.0
INSTALLATION OVERVIEW 3
2.0 INTRODUCTION 4
2.1 DIMENSIONS 5
2.1.1 WMFE1 (CORNER) 5
2.1.2 WMFE2 (SQUARE) 5
2.1.3 WMFE3 (LINEAR) 5
2.1.4 WMFE4 (CONVEX) 5
2.2 GENERAL INSTRUCTIONS 6
2.3 GENERAL INFORMATION 6
2.4 RATING PLATE INFORMATION 6
3.0 LOCATING APPLIANCE 7
4.0 INSTALLATION 8
4.1 MINIMUM CLEARANCE TO COMBUSTIBLES 8
4.2 INSTALLING THE APPLIANCE 9
4.2.1 WMFE1 9
4.2.2 WMFE2, WMFE3 AND WMFE4 10
5.0 FINISHING 11
5.1 BURN POT / BURNER INSTALLATION 11
5.1.1 WMFE1 11
5.1.2 WMFE2, WMFE3 AND WMFE4 11
5.2 GLASS FENDER INSTALLATION 12
5.3 WARNING PLATE LOCATION 12
6.0 OPERATING INSTRUCTIONS 13
6.1 FILLING THE BURNER / BURN POT 13
6.1.1 WMFE1 13
6.1.2 WMFE2, WMFE3 AND WMFE4 14
6.2 IGNITION 15
6.3 EXTINGUISHING THE FLAME 15
6.3.1 WMFE1 15
6.3.2 WMFE2, WMFE3 AND WMFE4 16
7.0 MAINTENANCE 16
7.1 CARE OF STAINLESS STEEL 16
8.0 REPLACEMENT PARTS 17
9.0 TROUBLESHOOTING 18
10.0 WARRANTY 19
11.0 SERVICE HISTORY 20
