Chapter Five--Control Setup
18
Panel Setup
BREAKER SETUP
This section explains how to setup your panel and
motorized breakers for remote operation. Repeat
this step any time breakers are added or removed.
To setup breakers, follow these steps:
1. Under Setup, go to the Panels tab.
2. Confi rm that all breakers are seated properly and have not
shifted during transport.
3. Click the “Scan Breakers” button. Motorized breakers are
represented in white, unmotorized breakers or blank spaces
are represented in gray.
Figure 5-4
4. If panel confi gurations are correct, click “Accept Changes”
