Page 11
139-0498-01.11
11
Chapter Four--Wiring
Figure 4-2: Control Wiring
Install and connect a standard Cat. 5e cable from the facility
network to the Controller Network port.
If DMX-512 is being used to control the panel, install and
connect a fi ve-pin DMX cable from the DMX source to the DMX
Input.
TCP/IP
DMX
LynTec
RPCM
DMX
IN
OUT
Network
Override
A
B
C
VAC L-N
VAC L-N
VAC L-N
AMPS
AMPS
AMPS
VAC N-G
AMPS
Hz
NEUTRAL
PHASE
OK
