COOK Laboratory Exhaust - Manual (Page 5)

3.
3 Filter / Holding Frame /
Clip Application
Guide
Pre
filter
Pleated/Panel/
Rigid/Bag/Filter
Filter
Clip
# of Clips
per Filter Filter
Access
Page
#
Figure
#
none 2" Panel/pleated C-70 4 Up/Downstream 2 1
none 4" Panel/pleated C-86 4 Upstream 3 2
none 4" Panel/Pleated C-77 4 Downstream 5 3
none 6" Rigid w/PH C-70 4 Upstream 2 4
none 12" Rigid w/PH C-70 4 Upstream 2 4
none Bag w/ PH C-70 4 Upstream 2 4
none 6" Rigid w/o PH C-90 4 Up/Downstream 6 5
none 12" Rigid w/o PH C-99 4 Up/Downstream 6 5
2" 6" or 12" Rigid
w/PH C-86 4 Upstream 3 6
2" Bag w/ PH C-86 4 Upstream 3 6
4" 6" or 12" Rigid
w/PH C-89 4 Upstream 4 7
4" Bag w/ PH C-89 4 Upstream 4 7
2"
6" Rigid w/o PH C-90 4 Upstream 6 5
C-79-1 4 7 8
4"
6" Rigid w/o PH C-90 4 Upstream 6 5
C-79-2 4 7 8
2"
12" Rigid w/o PH C-99 4 Upstream 6 5
C-79-1 4 7 8
4"
12" Rigid w/o PH C-99 4 Upstream 6 5
C-79-2 4 7 8
PH=Peripheral Header
