Chapter 3: Terminal Menu Operation and Structure
61202.070L1-1 Express L128/L128T User Manual 59
Security/Filter Defines
The Express L128/L128T can filter packets based on certain parameters within
the packet. The method used by the Express L128/L128T allows the highest
flexibility for defining filters and assigning them to a Connection List profile.
The filters are set up in two steps: (1) defining the packet types, and (2) adding
them to a list under the Connection List profile. See the section Connection List/
Filters on page 79 for examples of how to set up filter profiles. This menu is
used to define the individual filter defines based on packet type.
Filter Defines /MAC Filter Defines
Write security: 2; Read security: 3
The MAC filter is applied to bridge packets only. Bridge packets which are for-
warded by the bridge functionality of the Express L128/L128T are defined
here. Up to 32 MAC defines can be specified.
Name Identifies the filter entry
Src Addr 48-bit MAC source address used for comparison.
(hexadecimal format)
Src Mask Bits in the MAC source address which
are compared. (hexadecimal format)
Dest Addr 48-bit MAC destination address used
for comparison. (hexadecimal format)
Dest Mask Bits in the MAC destination address used
for comparison. (hexadecimal format)
MAC Type 16-bit MAC type field used for comparison.
(hexadecimal format)
Type Msk Bits in the MAC type field used for comparison.
(hexadecimal format)
