Rear panel, Continued – Sony HCD-C450 User Manual
Page 13

13
GB
1 AM antenna (21)
2 AUDIO 1 jacks (23)
3 AUDIO 2 jacks (23)
4 DIGITAL IN (OPTICAL) jack (24)
5 MONITOR OUT (VIDEO/S VIDEO)
jacks (23)
6 COMPONENT VIDEO OUT jacks (23)
7 SPEAKER jacks (19)
8 FM 75Ω COAXIAL antenna jack (21)
