Getting started
Identifying the parts
See the pages in parentheses for details of operation.
A Self-timer lamp (22)
B Flash (22)
C Shutter button (18, 23)
D
Zoom lever (20)
E Photocell window for flash
Do not block while recording.
F Tripod receptacle (bottom
surface)
Use a tripod with a screw length of
less than 6.5 mm (7/32 inch). You
cannot firmly secure the camera to
tripods having longer screws, and
may damage the camera.
G Lens
H Built-in microphone
Do not touch while recording.
I
Lens cap (supplied)
J ACC (Accessory) jack
K A/V OUT (MONO) jack (62)
Audio output is monaural.
L DC IN cover/DC IN jack (10, 13)
