Magnum VS –48 Vdc User Manual
Page 51
8.4. Mechanical
TWF0500H54B Rectifier
Dimensions (Overall)
5 in (12.7 cm) high x 2.75 in (7 cm) wide x 10.5 in (26.7 cm) deep
Dimensions (not including faceplate
or connectors)
5 in (12.7 cm) high x 2.5 in (6.3 cm) wide x 9.4 in (24 cm) deep
Weight
4 lb (1.8 kg)
Color
Black front, Yellow zinc sides and back
Mounting
Hot swappable. Secured with 2.5 mm captive screws
Magnum VS 50 Power System
Dimensions
5-1/4 in (13.3 cm) high x 17-1/4 in (43.8 cm) wide x 13 in (33 cm) deep
Weight
15 lb. (6.8 kg)
Color
Black Front, Yellow zinc sides and back
Mounting
19” Rack Mounting (23” Optional)
Magnum VS 100 Power System
Dimensions
10-1/2 in (26.6 cm) high x 17-1/4 in (43.8 cm) wide x 13 in (33 cm) deep
Weight
30 lb. (13.6 kg)
Color
Black Front, Yellow zinc sides and back
Mounting
19” Rack Mounting (23” Optional)
8.5. Environmental
(Operating)
-40ºC to +55ºC (+65ºC with reduced power output)
Ambient Temperature
(Storage)
-45ºC to +85ºC
(Operating)
0 – 85% RH (non-condensing)
Humidity
(Storage)
0 – 95% RH (non-condensing)
(Operating)
3000 m (9840 ft.)
Altitude
(Storage)
10000 m (39370 ft.)
