Magnum VS –48 Vdc User Manual
Page 48
8 Specifications
The overall system specifications can vary, depending upon the number of rectifier modules. Note that some
specification items are provided on a “per rectifier” basis and must be combined or totaled for a given system
configuration.
8.1. AC Input
TWF0500H54B Rectifier
Input Voltage Range
85 – 264 Vac
AC Frequency Range
47 – 63 Hz
Apparent Power Factor
99% Typical, 98% Minimum
Input Current (per Rectifier)
5.5 A @ 115 Vac
3.7 A @ 230 Vac
Turn on Time
2 Seconds
Magnum VS 50 Power System
Input Voltage Range
85 – 264 Vac
AC Frequency Range
47 – 63 Hz
Apparent Power Factor
99% Typical, 98% Minimum
Input Current
27.5 A @ 115 Vac
18.5 A @ 230 Vac
Magnum VS 100 Power System
Input Voltage Range
85 – 264 Vac
AC Frequency Range
47 – 63 Hz
Apparent Power Factor
99% Typical, 98% Minimum
Input Current
55 A @ 115 Vac
37 A @ 230 Vac
