Magnum VS –48 Vdc User Manual Page 49
8.2. DC Output
TWF0500H54B Rectifier
Output Voltage (factory set) 54.5 Vdc
Operating Voltage Range 44 – 58 Vdc
Efficiency 85% Typical
Over Voltage Protection 59.5 Vdc
Output Current per Rectifier 9.0 A Minimum Continuous at 115 Vac Input
10.5 A Minimum Continuous at 230 Vac Input.
Current Limit 9.3 A Maximum at 115 Vac Input
11.0 A Maximum at 230 Vac Input.
Power Output per Rectifier @
54.5 Vdc 490 W Continuous at 115 Vac Input
570 W Continuous at 230 Vac Input
Magnum VS 50 Power System
Output Voltage (factory
programmed) 54.0 Vdc
Operating Voltage Range 47 – 56.5 Vdc
Rated Output Current 50 A
Efficiency 85% Typical
Over Voltage Protection 59.5 Vdc
Output Current 45 A Minimum Continuous at 115 Vac Input
52.5 A Minimum Continuous at 230 Vac Input.
Current Limit 46.5 A Maximum at 115 Vac Input
55.0 A Maximum at 230 Vac Input.
Power Output @ 54.5 Vdc 2450 W Continuous at 115 Vac Input
2850 W Continuous at 230 Vac Input
