MDR-HW700DS
>
>
Location and function of parts
DP-HW700 Processor
Functions of buttons, indicators, and other parts on the processor are explained here.
Rear
HDMI IN jacks (IN 1/IN 2/IN 3)
These jacks input HDMI signals.
HDMI OUT jack
Outputs HDMI signals. This jack is compatible with ARC (Audio Return Channel)
.
TV (OPT) IN/OUT (THROUGH) jacks
Inputs or outputs optical digital audio signals.
LINE IN (L/R) jacks
These jacks input analog audio signals.
DC IN 12V jack
Connect the AC adaptor supplied to this jack.
Top
/
)
The processor turns on or enters standby mode alternately as you press the button.
Hold the button down for 3 seconds or longer to turn off the processor completely
(power off).
