Installation
25 9001909
Machine with Electric Heating
200-240V 3AC
200-240V 3 phase (3AC) should be connected to the
connectors “L1, L2, L3”. Refer to Figure 16.
The green/yellow grounding clamp has to be
connected to the grounding wire “PE”.
380-415V 3AC + N
380-415V 3 phase (3AC + N) has to be connected to
the connectors “L1, L2, L3”, the blue neutral to the
“N” connector. Refer to Figure 16.
The green/yellow grounding clamp has to be
connected to the grounding wire “PE”.
After electrical installation is complete, run the
machine through a test cycle and check for a clockwise
basket rotation during the extract step. If rotation is not
clockwise, disconnect the power from the machine and
have a qualified electrician reverse any 2 motor leads
at the AC drive terminal block.
Electrical Specifications
Voltage Designation Standard Electric Heat
Mo
del
Co
de
Vo
lta
g
e
Cy
cl
e
Phase
Wir
e
Full Lo
ad
Amp
s
Circuit
Br
eak
er
AW
G
/m
m
2
kW
Full Lo
ad
Amp
s
Circuit
Br
eak
er
AW
G
/m
m
2
kW
18
P 380-415 50/60 3 3+N+PE Not available 21 30 10/6.0 9
Q 200-240 50/60 3 3+PE Not available 27 30 10/6.0 9
X 200-240 50/60 1/3 2/3+PE 12 15 14/2.5 0.75 Not available
30
P 380-415 50/60 3 3+N+PE Not available 36 40 8/10.0 18
Q 200-240 50/60 3 3+PE Not available 49 60 6/16.0 18
X 200-240 50/60 1/3 2/3+PE 18 20 12/4.0 1.5 Not available
33
P 380-415 50/60 3 3+N+PE 18 20 12/4.0 1.5 44 50 8/10.0 18
Q 200-240 50/60 3 3+PE 18 20 12/4.0 1.5 63 70 4/25.0 18
X 200-240 50/60 1/3 2/3+PE 18 20 12/4.0 1.5 Not available
40
P 380-415 50/60 3 3+N+PE 18 20 12/4.0 1.5 44 50 8/10.0 18
Q 200-240 50/60 3 3+PE 18 20 12/4.0 1.5 63 70 4/25.0 18
X 200-240 50/60 1/3 2/3+PE 18 20 12/4.0 1.5 Not available
Table 6
