Specifications and Dimensions
General Specifications
Model 18 30 33 40
Overall Dimensions
Overall width 26 in.
(660 mm)
30.7 in.
(780 mm)
30.7 in.
(780 mm)
30.7 in.
(780 mm)
Overall height 40.9 in.
(1038 mm)
47.3 in.
(1202 mm)
54.15 in.
(1376 mm)
54.15 in.
(1376 mm)
Overall depth 29.1 in.
(739 mm)
33.1 in.
(842 mm)
33.07 in.
(840 mm)
37.01 in.
(940 mm)
Weight and Shipping Information
Net weight 465.2 lb.
(211 kg)
716.5 lb.
(325 kg)
811.30 lb.
(368 kg)
862.01 lb.
(391 kg)
Shipping weight 513.7 lb.
(233 kg)
782.6 lb.
(355 kg)
844.37 lb.
(383 kg)
921.53 lb.
(418 kg)
Shipping volume 22.5 ft
3
(0.8 m
3
)
34.7 ft
3
(1.3 m
3
)
42.83 ft
3
(1.21 m
3
)
45.98 ft
3
(1.3 m
3
)
Wash Cylinder Information
Cylinder diameter 20.9 in.
(530 mm)
25.6 in.
(650 mm)
26.77 in.
(680 mm)
26.77 in.
(680 mm)
Cylinder depth 13 in.
(330 mm)
15.76 in.
(400 mm)
15.75 in.
(400 mm)
19.69 in.
(500 mm)
Cylinder volume 2.7 ft
3
(76 l)
4.66 ft
3
(132 l)
5.12 ft
3
(145 l)
6.39 ft
3
(181 l)
Perforation size 0.12 in.
(3 mm)
0.12 in.
(3 mm) 0.12 in.
(3 mm) 0.12 in.
(3 mm)
Door Opening Information
Door opening size 11.8 in.
(300 mm)
11.8 in.
(300 mm)
15.75 in.
(400 mm)
15.75 in.
(400 mm)
Height of door bottom above floor 11 in.
(280 mm)
15 in.
(381 mm)
18.58 in.
(472 mm)
18.58 in.
(472 mm)
