Installation
9001909 16
Mechanical Installation
Frame Dimensions and Mounting Bolt
Location
Figure 7
IMPORTANT: Drawing is not to scale.
CFD67N
18 MODEL
20.87 in.
(530 mm)
25
.59
i
n
.
(69
0
mm)
23
.2
3 i
n
.
(59
0
mm)
25.98 in.
(660 mm)
1.18 in.
(30 mm)
2.26 in.
(65 mm)
0.74 in.
(18 mm)
1.18 in.
(30 mm)
2.26 in.
(65 mm)
