Installation
17 9001909
Figure 8
IMPORTANT: Drawing is not to scale.
CFD68N
30 MODEL
2
6
.1
8 in
.
(6
65 mm
)
25.51 in.
(648 mm)
1.44 in.
(36.5 mm)
2.60 in.
(66 mm)
0.71 in.
(18 mm)
29
.0
6 i
n
.
(73
8
mm)
30.71 in.
(780 mm)
1.44 in.
(36.5 mm)
2.60 in.
(66 mm)
