Installation
9001909 18
Figure 9
IMPORTANT: Drawing is not to scale.
CFD541N
CFD541N
2
8
.86 in.
(7
33 mm
)
26.77 in.
(680 mm)
1.97 in.
(50 mm)
.87 in.
(22 mm)
1.97 in.
(50 mm)
33 MODEL
1.34 in.
(34 mm)
26.
18 i
n
.
(665
m
m
)
1.34 in.
(34 mm)
30.71 in.
(780 mm)
