The PCM-9587 requires several cables for normal operation. You can make them
yourself or purchase an optional cable kit assembly, which includes the following
D.1
PCM-10586-6200E Cable kit for PCM-9587
Table D.1: PCM-10586-6200E wiring kit 9587
Part No.
Cable Description
PCM-9587F
Connector
Terminating Connector
1701340603
Dual floppy, 3.5" and
5.25" (34p)
CN14
34-pin dual floppy
1700260250
Parallel Port
CN16
26pin,female DSUB
1700001296
VGA CRT
CN7
2 x 8-pin header (2 mm) 15-pin
DSUB
1703060191
KB/mouse cable
CN27
6-pin circular DIN
1701400181
COM 1-4 cable
CN21
40-pin, 9-pin male DSUB x 4
1700160160 Audio
cable
CN4
F3.5 mm 16-pin, 5 female phone
jacks
1701400452
3.5" IDE DMA/66 (40p) CN15
40-pin, 2.54 mm, female IDC
(450 mm)
1703100260
USB cable
CN20
10-pin, IDE 2.0 mm, USB x 2 (26
cm)
1700071000
SATA cable
CN23
7P/7P 100CM
1703050106
TV-out cable
CN2
Wire 10 cm 5P TV-out
1700000410
TMDS cable
CN9
Cable DVI- 26P/DF13-20P 20 cm
1701100202
Network, 10/100 Base-T CN11
RJ45 8-pin modular
