63
PCM-9587 User Manual
Appendix B
P
in Assignments
B.27
Mini PCI Connector(CN29)
B.28
CompactFlash Card Connector (CN30)
Table B.27: Mini PCI Connector (CN29)
Pin
Signal
Pin
Signal
1
TIP Key
2
RING Key
3
8PMJ-33, 4
4
8PMJ-13, 4
5
8PMJ-63, 4
6
8PMJ-23, 4
7
8PMJ-73, 4
8
8PMJ-43, 4
9
8PMJ-83, 4
10
8PMJ-53, 4
11
LED1_GRNP 12
LED2_YELP
13
LED1_GRNN 14
LED2_YELN
15
CHSGND
16
RESERVED
17
INTB# 18
5V
19
3.3V 20
INTA#
21
RESERVED
22
RESERVED
23
GROUND
24
3.3VAUX
25
CLK 26
RST#
27
GROUND
28
3.3V
Table B.28: CompactFlash Card Connector (CN30)
Pin
Signal
Pin
Signal
1
GND
2
SDD3
3
SDD4
4
SDD5
5
SDD6
6
SDD7
7
SDCS#1
8
GND
9
GND
10
GND
11
GND
12
GND
13
+5V
14
GND
15
GND
16
GND
17
GND
18
SDA2
19
SDA1
20
SDA0
21
SDD0
22
SDD1
23
SDD2
24
NC
25
NC
26
NC
27
SDD11
28
SDD12
29
SDD13
30
SDD14
31
SDD15
32
SDCS#3
33
NC
34
SDIOR
35
SDIOW
36
+5V
37
IRQ15
38
+5V
39
CSEL
40
NC
41
IDERST
42
SDIORDY
43
NC
44
+5V
45
SDDASP
46
S66DET
47
SDD8
48
SDD9
49
SDD10
50
GND
