PCM-9587 User Manual
54
B.7
VGA Connector (CN7)
B.8
LVDS Connector (CN8)
Table B.7: VGA Connector (CN7)
Pin
Signal
Pin
Signal
1
VGA_R
2
VGA_VCC
3
VGA_G
4
GND
5
VGA_B
6
NC
7
NC 8
VGA_DATA
9
GND
10
VGA_HS
11
GND
12
VGA_VS
13
GND
14
VGA_CLK
15
GND
16
NC
Table B.8: CN8 LVDS connector
Signal
Pin
Pin
Signal
VDD_FP
1
2
VDD_FP
GND
3
4
GND
VDD_FP
5
6
VDD_FP
YAM0
7
8
YBM0
YAP0
9
10
YBP0
GND
11
12
GND
YAM1
13
14
YBM1
YAP1
15
16
YBP1
GND
17
18
GND
YAM2
19
20
YBM2
YAP2
21
22
YBP2
GND
23
24
GND
CLKAM
25
26
CLKBM
CLKAP
27
28
CLKBP
GND
29
30
GND
DCLK
31
32
DDAT
GND
33
34
GND
YAM3
35
36
YBM3
YAP3
37
38
YBP3
BKLTEN
39
40
NC
