3.1
Introduction
The PCM-9587 system BIOS and custom drivers are located in a 512 Kbyte, Flash
ROM device, designated U6. A single Flash chip holds the system BIOS, VGA BIOS
and network Boot ROM image. The display can be configured via CMOS settings.
This method minimizes the number of chips and difficulty of configuration. To set dif-
ferent types of LCD panels, please choose “panel type” from the “integrated peripher-
als” menu in CMOS setup.
3.2
Connections to Standard LCDs
The following tables illustrate typical LCD connection pinouts for the PCM-9587.
3.2.1
LG LM150X06 (1024x768(16 colors) LVDS LCD)
* LCD connector type: HRS DF 19K-20P-1H or compatible
Table 3.1: Connections to LCD/ Flat Panel (CN8)
LCD Connector Flat Panel Connector
Unipac-UB104S01 DF-13 40P
Pin
Signal
Pin
Signal
1
VCC
1
3.3V
2
VCC
2
3.3V
3
GND
3
GND
4
GND
4
GND
5
RxIN0-
7
LVDS_YAM0R
6
RxIN0+
9
LVDS_YAP0R
7
GND
11
GND
8
RxIN1-
13
LVDS_YAM1R
9
RxIN1+
15
LVDS_YAP1R
10
GND
17
GND
11
RxIN2-
19
LVDS_YAM2R
12
RxIN2+
21
LVDS_YAP2R
13
GND
23
GND
14
CKIN-
25
LVDS-CLKAMR
15
CKIN+
27
LVDS-CLKAPR
16
GND
29
GND
17
NC
18
NC
19
GND
33
GND
20
GND
34
GND
