49

PCM-9587 User Manual

Appendix A

P

rogramming

the

G

PIO

and

Watchdog

Timer

MOV AL,F2H;

OUT DX,AL

MOV DX,2FH

MOV AL,00H;Set GPIO is normal not inverter

OUT DX,AL;

MOV DX,2EH

MOV AL,F1H

OUT DX,AL

MOV DX,2FH

MOV AL,**H; Put the output value into AL **H

OUT DX,AL

---------------------------------------------------------------------------------------------------------------

Exit extended function mode |

---------------------------------------------------------------------------------------------------------------

MOV DX,2EH

MOV AL,AAH

OUT DX,AL

Note!

The input/output data (**) is a value of time interval. The value range is
from 01 (hex) to 3F (hex), and the related time interval is 1 sec. to 62
sec.

Data Time Interval

01

1 sec.

02

2 sec

03

3 sec

04

4 sec
