Diagnostics
35 70444801
Alarms Menus The Alarms Menu contains three screens of
information. On the first screen, Alarms (1 of 3), the
eight most recent alarms will contain Cycle Number,
Segment Number, Alarm Type, and the Date/Time of
the Alarm.
The second screen, Alarms (2 of 3), alarm counts list 1
through 8. Alarm counts consist of how many times a
specific alarm has occurred.
The third screen, Alarms (3 of 3), is a continuation of
the alarm counts 9 through 16.
Press the or keypad to navigate to the
different screens in the Alarms Menu. Press the
keypad to go from screen 1 to screen 3. The actual
menus are informational only and cannot be navigated.
Press the
keypad to return to display to
Diagnostic Menu or the Run Diagnostic Menu.
Machine ID Menu
The Machine ID Menu provides several different types
of manufacturing and machine information that can be
useful to the user and technician. The Machine ID
Menu cannot be navigated. Pressing the
keypad
will return to Diagnostic Menu or the Run Diagnostic
Menu.
TMB1400R
Figure 45
TMB1330R
Figure 46
TMB1363R
Figure 47
Alarms (1 of 3)
ALARM COUNTS
C01: S02 Cabinet High Limit 12/05 03:34
C02: S05 Heat 11/29 15:55
C38: S01 Fan Motor Contactor 08/14 07:27
C07: S04 Open Thermistor 06/28 18:24
C01: Scd Open Thermistor 04/08 08:05
Alarms (2 of 3)
ALARM COUNTS
Air Flow Switch 1 Count: 0
Air Flow Switch 2 Count: 0
Air Flow Switch Bounce Count: 0
Cabinet High Limit Count: 1
Stove 1 High Limit Count: 0
Stove 2 High Limit Count: 0
Open Thermistor Count: 2
Short Thermistor Count: 0
Alarms (3 of 3)
ALARM COUNTS
Fan Motor Contactor Count: 1
Fan Motor Centrifugal Sw Count: 0
ICM Lockout Alarm Count: 1
Heat Count: 1
Rotation Count: 0
Moisture Sensor Count:
IR Count: 5
0
Network Count: 18
TMB1332R
Figure 48
Machine ID
Model: UT030NUOG2K0W01
Serial #: 1107002759
Install Date: 07/01/2011
Machine Type: 30
Control SN: 11410113
Front End SW: 1
Display SW: 1
Node Number: 250
